Lumina SQ9 is the ideal work light for those seeking a blend of sleek design and powerful performance in a compact form. This work light, AR marked and approved as reverse light, delivers an impressive 3426 actual lumens with a 5000K color temperature, ensuring bright and clear illumination. With a 1 lux brightness at 66 meters and a wide 90° beam angle, Lumina SQ9 provides extensive coverage, lighting up a larger work area with sufficient intensity to ensure safe and efficient task completion. Experience the perfect balance of style and functionality with Lumina SQ9.

Specifications:

• Range: 47 meters (1 lux), 94 meters (0.25 lux)
• Approved as reverse light R148 (R23) and ADR-approved
• 90° flood beam with wide coverage
• Lumen: 2929 (theoretical), 1758 (actual)
• Neutral white light (5000K)
• IP67, IP69K (water and dust resistant)
• CISPR25 class 3, ECE R10 (EMC compliant)
• Temperature control system
• Voltage: 10-30V
• 1.78A at 12V and 0.84A at 24V
• 12 x Osram LEDs (total 18W)
• Aluminum housing and polycarbonate lens
• Stainless steel mounting bracket included

Dimensions:

• Width: 100 mm
• Height: 121 mm
• Depth: 40 mm
• 50 cm cable with 2-pole DT connector

Note: The DT connector should not be cut, as this increases the risk of moisture damage and voids the warranty. A DT connector (male) with a splice is included with the product.

Technical information:
Lumen (theoretical) 6591
Light temperature (K) 5000
Unit st
Manufacturer Ledson
Warranty 36 Months
Shape (round, oval, straight, etc.) Square
IP rating IP69K
Light source LED
Function Auxiliary light
Manufacturer Ledson
